ORION
Automotive Radar for ADAS & ARAS
Starkenn Radar is a proprietary, software-defined automotive radar designed for accurate range and relative speed measurement to support ADAS and ARAS applications across commercial, passenger, and industrial vehicles.
Why Starkenn Radar?
Designed and developed on Starkenn’s Made-in-India automotive-grade radar technology.
Tested across road, fleet, and mining environments to ensure dependable performance.
Engineered to operate reliably in dense traffic, varied terrain, and demanding conditions.
Designed to support applications such as MOIS, BSIS, FCWS, AEBS, & other radar-based safety & assistance systems.
Engineered for Real-World Conditions
Our antenna is engineered to provide depth perception as well as elevation perception thus being fine-tuned for ADAS applications to generate rich and dense point cloud data. The hardware processes enormous amounts of point cloud data coming from numerous objects on the road in real-time and Starkenn's novel algorithms rapidly process this data to segregate the objects imminent to crash into the ego vehicle at frame rates higher than 10 fps. Our radar measures the velocity of these objects and tracks them, ensuring no last-minute surprises, weeding out the dangerous false negatives and reducing false positives
Technology At Glance
Detection range
Up to 160 m
Up to 50 m
Horizontal FOV
± 70°
Up to 6 m (two adjacent lanes)
Vertical FOV
± 15°
< 300 ms
Typical startup time
< 300 ms
< 300 ms
Length
83 mm
83 mm
Breadth
62 mm
62 mm
Height
15 mm
15 mm
Mass
Customizable
Customizable
IP rating
67
67
Frequency range
76 – 77 GHz, 77 – 81 GHz
76 – 77 GHz, 77 – 81 GHz
Nominal supply voltage
12 / 24 V
12 / 24 V
Power consumption
5 W – 15 W
5 W – 15 W
Operating temperature
-40 °C to +85 °C
-40 °C to +85 °C
Storage temperature
-40 °C to +125 °C
-40 °C to +125 °C
1 High speed CAN interface
Up to 5 Mbps
Up to 5 Mbps
1 Private CAN
-
-
High-Precision Automotive Radar Platform
Starkenn's indigenously developed radar provides accurate range. The platform supports ADAS and ARAS use cases across commercial, passenger, and industrial vehicles.
Designed for reliable operation in complex traffic, low-visibility conditions, and harsh environments, Starkenn Radar delivers consistent performance to support braking, warning, and rider assistance systems.
Range Measurement with 98.3% Accuracy
Long-Range & Short-Range Perception (2m–150m)
Software-Defined & Configurable Radar Profiles
Free-Space Mapping & Imminent Collision Detection
